DIY Kit 15KV High Voltage Inverter Generator Spark Arc Ignition Coil
Module 3.7VUSD $13.99
Condition : New
Free Shipping
{{variant_type_name}} :
Notify me when the price drops
We will email you if we find a lower price on this product!
Description:
⚡ DIY Kit 15KV High Voltage Inverter Generator Spark Arc Ignition Coil Module (3.7V)
Compact high-voltage step-up DIY kit designed for low-voltage DC input and experimental electronics projects that require a visible high-frequency arc output. This kit uses a small 15KV-class transformer and a simple, hobby-friendly driver circuit, making it suitable for electronics enthusiasts, educational demonstrations, science projects, and other controlled bench-testing applications.
This is a DIY kit, not pre-assembled. Assembly and soldering are required before use.
🔧 Key Features
• DIY Kit Format — supplied as individual parts for user assembly
• Designed for 3.7V–4.2V DC Input — intended for low-voltage DC operation in the included configuration
• Approx. 15KV Listed Output — high-voltage step-up design for short arc generation under proper conditions
• Simple, Reliable Circuit Topology — convenient for electronics hobby work and educational experimentation
• Compact PCB Layout — small board footprint for portable or bench projects
• Visible High-Frequency Arc Output — suitable for controlled demonstration of high-voltage effects
• Includes Main Build Components — transformer, PCB, resistor, diode, transistor, heatsink, switch, hardware, and pin header
🧠 Product Description
This kit is intended for experimental high-voltage generation from a 3.7V–4.2V DC source. When properly assembled and powered within its intended input range, seller listings describe it as producing an approximate 15KV high-voltage output capable of generating a short visible arc.
It is commonly marketed for science demonstrations, educational electronics projects, negative-ion / ionization experiments, and other small DIY high-voltage builds. Real arc length and performance depend on the power source, assembly quality, wiring, and load conditions.
To avoid ambiguity: this product is best described as an unassembled low-voltage-to-high-voltage experimental arc generator kit. It is not a finished consumer appliance, not plug-and-play, and not intended for beginners or unsupervised use.
📐 Typical Specifications
• Product Type: DIY high-voltage inverter / spark arc generator kit
• Input Voltage: DC 3.7V–4.2V
• Input Current: < 2A
• Listed Output Voltage: approx. 15KV
• Listed Output Current: ≤ 0.4A
• Typical Bipolar Arc Gap: ≤ 0.5 cm
• Transformer Size: approx. 27 × 16 × 21 mm
• PCB Size: 4.2 × 3.2 × 0.16 cm
Important Input Note: the included configuration is intended for 3.7V–4.2V DC. 12V input is not recommended in the as-supplied kit configuration because it may damage the transistor or transformer.
🧪 Typical Applications
• High school / classroom science demonstrations
• Electronics hobby experiments
• Educational high-voltage demonstrations
• Negative ion / ionization project work
• Small DIY research and prototype builds
⚠️ Important Safety Notes
• High Voltage Hazard — this kit can generate a dangerous high-voltage arc
• Shock / Burn Risk — do not touch the output leads or exposed high-voltage section during operation
• Fire / Ignition Risk — keep away from fuels, vapors, paper scraps, solvents, dust, and other flammable materials
• For Advanced Users Only — assembly and operation require electronics knowledge and safe handling practices
• Use Only in Controlled, Dry, Ventilated Areas
• Adult Supervision Required for any educational or student use
• Power Source Not Included
📦 Package Includes
• 1 × 15VKE Step-Up Transformer
• 1 × PCB Board
• 1 × 120Ω Resistor
• 1 × UF4007 Ultra-Fast Recovery Diode
• 1 × N20 Transistor
• 1 × Heat Sink
• 1 × M3 × 6 Screw
• 1 × Boat Switch
• 1 × 3-Pin Header
💥 Volume Discount — Buy More & Save
• 10% OFF for 2 units
• 15% OFF for 3 units
• 20% OFF for 4+ units
Discount auto-applied at checkout.
🇺🇸 Premium Support & Shipping
• US Stock / Fast Shipping — 2–4 day delivery from Oklahoma, USA
• Your purchase supports a US-based small business
• Quality Checked — spot-checked before shipping
• Easy Returns — 30-day returns; we pay return shipping
• Professional Packaging — safe delivery, 100% guaranteed
